APU Starting Panel



APU Master SW



Opens the APU inlet flap and causes the APU SD page to appear





In/On



Causes the APU shut down sequence to begin.



Out/Off



Illuminated when an automatic or emergency shut down occurs





FAULT



Indicates the APU flap is opening





APU Start SW



Begins the APU start sequence





Pressed



ON/R



Illuminated when the APU is available to supply electrical and/or bleed air to the aircraft.



AVAIL



Indicates that the APU is starting, Light extinguishes at APU N > 95%





ON



The APU is described in the aircraft systems under APU.





This is a momentary press push button. It does not latch in.





The APU master button and On button are located on the lights switch panel at the front of the overhead panel.
