PFD : ADI



In the center of the PFD is the Attitude ball. This is a digital display of the the ADI and shows the aircraft's attitude and F/D information along with various attitude limits.



At the bottom of the ADI, the radio altitude is displayed, if the aircraft is within 2500 ft of the ground.



Pitch and roll limits are displayed in green on the ADI if the Flight Control System is I the Normal Mode.
